Detroit Iron® DPRGM-153-75TWD-SUP - Wiring Diagrams

Specifications

Features

• Developed to preserve valuable data about antique and classic rides
• Made with the utmost care for your specific year, make and model
• Designed to provide the exact copy of the original manual

Product Details

Wiring Diagrams by Detroit Iron®. This 1975 Chevy GMC Truck Wiring Diagrams Supplement - 11x26 inch Foldouts is a high-quality, licensed PRINT reproduction of the wiring diagrams authored by Chevrolet Motor Division and published by Detroit Iron. This OEM factory manual is 8.5 x 11 inches, STAPLED bound, shrink-wrapped and contains 12 pages of 11x26 inch foldout detailed factory wiring diagrams. Wiring Diagrams were originally written by the automotive manufacturer to be used by their dealership mechanics. The following 1975 Chevrolet, GMC models are covered: C10, C10 Suburban, C20, C20 Suburban, C30, K10, K10 Suburban, K20, G10, G20, G30, P10, P20, P30, C15, C15 Suburban, C25, C25 Suburban, C35, K15, K15 Suburban, K25, K25 Suburban, G15, G25, G35, P15, P25, P35. NOTE: This is a SUPPLEMENT. It covers only the servicing of NEW components that differ from what is described in the manual it supplements. It is designed to be used with the parent manual referenced in the title. You will need BOTH manuals for complete service information. This factory-written Detroit Iron wiring diagram set is perfect for the restorer or anyone working on one of these vehicles.
