DS18® PRO-TW720L - 1.6" Shallow High Compression Neodymium Super Bullet Tweeter

0 reviews|Item # mpn5242749519
Universal Fit
Fitment notes:
  • Not Vehicle Specific
Authorized Dealer
$59.95
In Stock (185) - Ships in 2 to 3 days
Have a Question? Ask a Specialist
888-903-4343Live Chat

Vehicle Fitment

This part is universal

Specifications

SKU
PRO-TW720L
Nominal Diameter
2.28" / 58mm
Nominal Impedance
4 Ohms
AES Power Handling
70W
Program Power Handling
140W
Peak Power Handling
280W
Sensitivity (1w/1m)
103 dB
Frequency Response
2K-20KHz
Recommended Hi Pass Crossover
3KHz
Pair or Single
Single
Body Material
Aluminum
Body Color / Finish
Black
Bullet Material
Translucent ABS with RGB LED
Rubber Gaskets
Yes, 1 x 5mm + 1 x 1.9mm (thickness)
Locknut ring
Yes, 2 x Aluminum 4.7mm (thickness)
RGB Wire
Yes, with fast connector
Voice Coil Diameter
1" / 25.4mm
Voice Coil Former Material
KSV
Winding Material
Aluminum Round Wire
Diaphragm Material
Polyether Ether Ketone (PEEK)
Magnet Material
Neodymium
Magnet Size
0.96"x0.27"x0.27" / 24.5x7x7mm
Overall Diameter
2.28" / 58mm
Overall Depth
1.93" / 49mm
Front Mount Baffle Cutout
1.73" / 44mm
Mounting Depth
1.77"~1.26" / 45~32mm
Product Weight
0.8 lbs
Product Dimensions
3.5 x 2.5 x 2.75
M/C Weight
26 lbs
M/C Dimensions
14 x 11.5 x 6.75
M/C QTY
30
Sold In
Piece

Features

  • 1.6" Shallow High Compression Super Bullet Tweeter
  • RMS Power: 140 Watts(280 Watts Peak)
  • Impedance: 4 Ohm ~ 103dB
  • Neodymium Magnet
  • Adjustable Surface Mount / Single
  • Easily Repaired With The PRO-TW720LVC

Product Details

Universal 1.6" Shallow High Compression Neodymium Super Bullet Tweeter by DS18®. 1.6" Shallow High Compression Neodymium Super Bullet Tweeter 140 Watts 1" Polyether Ether Ketone 4-Ohm Vc With RGB LED Lights. 140 Watts 1" Polyether Ether Ketone 4-Ohm Vc With RGB LED Lights. DS18 PRO-TW720L . 1.6" Shallow High Compression Neodymium Super Bullet Tweeter 280 Watts 1" Aluminum Voice Coil 4-Ohms WITH RGB LED Lights . Designed by the audio experts at DS18, the PRO-TW720L is the epitome of precision and performance, delivering a concert like experience every time you turn up the volume. DS18’s PRO-TW720L professional grade super tweeter effortlessly recreates sound with astonishing clarity and accuracy, allowing you to discern every subtle nuance and delicate detail. Indulge your senses with the mesmerizing RGB LED lights integrated into the PRO-TW720L. Experience the sensation of being in the heart of the action, as if you were standing right beside your favorite artist on stage. The PRO-TW720L's sleek bullet design not only exudes elegance but also serves a purpose. Its aerodynamic shape allows for extreme range volume projection, ensuring your music reaches great distances with extraordinary clarity. Crafted from high-quality aluminum and featuring a bullet dust cover, these tweeters are built to last. The neodymium magnet structure further enhances durability while maintaining a compact size, making it compatible with a wide range of applications. Featuring a robust KSV 4-Ohms 1-inch voice coil, each tweeter is rated at an impressive 60W AES, 140W Program, and a staggering 280W Peak Power Handling. Say goodbye to distortion and welcome crystal-clear, distortion-free audio that cuts through any surrounding noise effortlessly. We understand that time is of the essence, which is why the PRO-TW720L is designed for hassle-free installation. Our drop-in voice coil kits enable quick repairs that can be completed in less than five minutes, ensuring your sound system is always up and running. With a mounting depth of only 1.77" - 1.26" inches, these tweeters seamlessly integrate into your existing setup without any modifications.

Brand:
Part Number:
PRO-TW720L
UPC:
810097260665
Alternate MPN:
PROTW720L
