DS18® SDX-P100 - Digital Media Receiver

3 reviews|Item # mpn5242749405
Universal Fit
Fitment notes:
  • Not Vehicle Specific
Authorized Dealer
$179.95
In Stock (265) - Ships in 2 to 3 days
Have a Question? Ask a Specialist
888-903-4343Live Chat

Vehicle Fitment

This part is universal

Specifications

SKU
SDX-P100
Nominal DIN Size
1-DIN
Rated Power Voltage
14.4V
Voltage Operation
9.6-15 Volts
Maximum Current Consumption
15A
Temperature Operation
0~60°C / 32~140°F
Screen Size
4" / 104mm
Display Type
LCD Dots
Buttons / Controls
ABS
Backlight Illumination Type
RGB / 3 Zones
Body Material / Color / Finish
Steel / Bronze
Maximum Power Output (Peak)
4x40W
Continuous Power Output (RMS)
4x15W
Minimum Impedance
4 Ohms
Frequency Response
20Hz-20KHz
Pre-Output Level (RCA)
3V / 3.5V (Subwoofer)
Equalizer Bands
24 Bands
Equalizer Gain
+ / - 9dB
Crossover
3-Way
Crossover Slope
6 / 12 / 24 dB/Oct
Time Alignment
0~25ms / 0~850cm
Audio Control
Subwoofer Level, Fader, Balance, Loudness
Frequency Range (FM)
87.5 - 108.0 MHz
Frequency Range (AM)
522 - 1620 KHz
Presets Memory
18 FM / 12 AM
Region
Europe, America, Asia, Russia
Sensitivity Adjustment
Local / DX
Version
4.2
Services
Hands Free Calls, Audio Streaming, APP Remote Control
Audio Protocols
A2DP, AVRCP, HFP
Range
32ft / 10m
Type / Class
2.0, 3.0 / FAT 16, FAT32
Format Files Supported
FLAC (16 Bit), WAV, AAC, APE, MP3
Max Memory Size Reader
64 Gb
Max Current USB Charger
1A
Number of Ports
1 (Front)
A/V Aux Input
Yes, Front 3.5mm Jack (2V Max)
Microphone
Yes, Built-In / External Mic Input
Remote Control (SWC)
Yes, 3.5mm Jack Input
Remote Control (Handset)
Yes, Card Type with Rubber Buttons
APP Control
Yes, (Android Devices)
Overall Width (Chassis)
7" / 178mm
Overall Height (Chassis)
1.96" / 50mm
Overall Depth (Chassis)
4" / 104mm
Overall Width (Bezel Frame)
7.4" / 188mm
Overall Height (Bezel Frame)
2.2" / 58mm
Overall Depth (Bezel Frame)
0.98" / 25mm

Features

  • Digital Media Single Din Receiver
  • Mech-Less ~ Remote Control APP
  • BT ~ USB ~ AUX
  • DSP ~ EQ ~ AM/FM
  • SUB Output ~ SWC Output
  • Multi Color Illumination~ 4" Display

Product Details

Universal Digital Media Receiver by DS18®. Digital Media Receiver Single Din DSP APP Bluetooth Audio and Calling Head Unit Aux Input USB Mechless AM/FM Radio Receiver 3V + 3.5V Subwoofer. Single Din. DSP. APP. Bluetooth Audio and Calling Head Unit. Aux Input. USB. Mechless. AM/FM Radio Receiver. 3V + 3.5V Subwoofer. DS18 SDX-P100 . Single DIN Digital Media Receiver With DSP / BT / USB / APP / AUX . Ready for the ultimate in-car audio experience? DS18’s SDX-P100 offers a full audio command center in a sleek, single DIN design that’s easy to install and fully loaded with features. Connect Your Devices . The SDX-P100 keeps your music at your fingertips. Enjoy 30 preset AM/FM stations, plus USB playback supporting high-quality audio formats including FLAC, WAV, AAC, APE, and MP3. Bluetooth lets you wirelessly stream your favorite playlists and take hands-free calls on the go. Customize Your Sound . With 3.5V RCA outputs and a built-in DSP, the SDX-P100 gives you full command over your sound. Fine-tune with time alignment and 2/3-way crossover options. Sculpt your soundstage with a 24-band graphic equalizer and tweak volume, subwoofer level, balance, and fader for a personalized listening experience. Vibrant Display . The vibrant 4" LCD screen delivers clean, easy-to-read visuals. Dynamic multi-color LED backlighting with 3-zone RGB illumination lets you set the vibe to match your ride. Powerful Performance . The SDX-P100 pumps out up to 40W x 4 MAX power and a solid 13W x 4 RMS! Expect audio that hits harder and cleaner than ever before. Control at Your Fingertips . Download DS18’s SDX Remote Control App for iOS or Download DS18’s SDX Remote Control App for Android and manage your receiver settings, DSP features, and audio controls directly from your smartphone. Or, use the included wireless remote to command your setup without needing steering wheel interface systems. The SDX-P100 is engineered to give your dash a serious audio upgrade that’s built to outlast and outperform.

Brand:
Part Number:
SDX-P100
UPC:
810097264489
Alternate MPN:
SDXP100

Reviews

(3)
Only authorized customers can leave a review on our website. We would love to know what you like or dislike about the product. Share your opinion on product quality, appearance, installation, and other characteristics.
/5
1-3 of 3 Reviews
5 of 5
Asking
Will it fit a 2005 Chrysler 300 Touring?
DS18® - 6.9" Touchscreen Mechless Double-Din Headunit with Bluetooth, USB and Mirror Link
Posted by Customer / January 12, 20222005 Chrysler 300
5 of 5
Works Well for the Price
Easy install and support staff very helpful.
DS18® - 6.9" Touchscreen Mechless Double-Din Headunit with Bluetooth, USB and Mirror Link
Posted by gary (Katy, TX) / June 30, 20212006 Toyota Tacoma
5 of 5
Great Unit for the Price - Would Buy Again
I had limited knowledge of the DS18 brand name before this purchase, but it was positive. The real selling point was the "in stock" feature for me. I don't need another android or apple device since I paid enough for my cell phone already. This installed nicely in my tacoma with ample room to spare. At this price point the features make this a wise purchase. Customer Support is excellent and assisted me troubleshooting what ended up as a clunky reverse camera connection.
DS18® - 6.9" Touchscreen Mechless Double-Din Headunit with Bluetooth, USB and Mirror Link
Posted by gary (Katy, TX) / June 27, 20212006 Toyota Tacoma
