DS18® PRO-HY8MSL - PRO Shallow Coaxial Hybrid Mid-Range Loudspeaker

Name: DS18® PRO-HY8MSL - PRO Shallow Coaxial Hybrid Mid-Range Loudspeaker
Brand: DS18
SKU: mpn5242749490
Price: 94.95 USD
Availability: InStock
Rating: 3 (2 reviews)

2 reviews|Item # mpn5242749490

Universal Fit

Fitment notes:

Not Vehicle Specific

Authorized Dealer

$94.95

In Stock (150) - Ships in 2 to 3 days

See similar products

Have a Question? Ask a Specialist

888-903-4343Live Chat

Vehicle Fitment

This part is universal

Specifications

SKU	PRO-HY8MSL
Nominal Diameter	8" / 203.2mm
Nominal Impedance	8 Ohm
RMS Power Handling	200W
MAX Power Handling	400W
Sensitivity (1w/1m)	98dB
Frequency Response	100Hz - 20Khz
Recommended HI Pass Crossover	120Hz
Number of ways	2 ways
Pair or Single	Single
Grill Included	Yes
Voice Coil Diameter	2" / 50.8mm
Voice Coil Former Material	KSV
Winding Material	CCAW
Cone Material	Paper
Surround Material	Cloth
Basket Material	Steel
Basket Color/Finish	Black
Magnet Material	Ferrite
Magnet Weight	29.5 Oz
Equivalent Volume Vas	7.85L / 0.277ft3
Excursion (one way) Xmax	2mm
Free Air Resonance Fs	114Hz
Mechanical Factor Qms	6.282
Electrical Factor Qes	0.984
Total Factor Qts	0.851
Mechanical Mass Mms	16.357g
Mechanical Compliance Cms	118.033 mm/N
BL Factor BL	8.817
Voice Coil Inductance Le	12.06mH
Cone Area Sd	216.424 Cm2
DC Resistance Re	6.5 ohm
Mechanical Mass w/o air Mmd	14.527g
Voice Coil Diameter_1	1" / 25.4mm
Voice Coil Former Material_1	Kapton
Winding Material_1	CCAW
Diaphragm Material	Titanium
Magnet Material_1	Neodymium
Horn Diameter	3" / 76.2mm
Overall Diameter	8.2" / 209mm
Overall Depth	4" / 102.5mm
Front Mount Baffle Cutout	7.16" / 182mm
Mounting Depth	3.15" / 80mm
Motor Diameter	5.27" / 134mm
Gross Single Unit Weight	5.75
Single Unit Box Dimensions L x W x H (Inches)	9 x 9 x 4.75
Quantity of Units in Master Carton	8
Gross Master Carton Weight	49
Master Carton Dimensions L x W x H (Inches)	18.5 x 18.5 x 10.25

Features

8" Shallow Hybrid Coaxial Mid-Range w/Driver
RMS Power: 200 Watts(400 Watts Peak)
Impedance: 8 Ohm
Ferrite & Neodymium Magnets
With Grill
98dB

Product Details

Universal PRO Shallow Coaxial Hybrid Mid-Range Loudspeaker (PRO-HY8MSL) by DS18®. PRO 8" Shallow Coaxial Hybrid Mid-Range Loudspeaker with Built-in Driver 200 Watts Rms 8-Ohm. DS18 PRO-HY8MSL . 8" Hybrid Slim Loudspeaker With 1" Compression Driver Horn . Get LOUD in tight spaces with DS18’s PRO-HY8MSL—the slim-mount hybrid speaker made for motorcycles, ATVs, Slingshots, and more. Hybrid Power in a Compact Package . The PRO-HY8MSL combines a powerful 8" midrange woofer with a 1" titanium compression driver horn, packing serious output into a slim 3.15" mounting depth. This speaker cuts through wind noise or engine rumble LOUD and clear with 200W RMS / 400W MAX power handling and a bold 98dB sensitivity across 100Hz-20KHz. High-End Components, No Compromise . Crafted with a paper cone, cloth surround, and a 2" KSV voice coil, this loudspeaker delivers smooth midrange and vocal response. The steel basket and 29.5oz ferrite magnet give it structure and strength, while the titanium diaphragm and neodymium motor in the horn ensure razor-sharp highs that carry far and stay crisp. Designed for Real-World Rigs . This speaker is for real riders who want clean sound in performance machines. If your vehicle has room for 8’s, the PRO-HY8MSL belongs in it.

DS18® - Manual DS18® - Product Catalog Made In USA DS18 Authorized Dealer

Brand:

DS18

Part Number:

PRO-HY8MSL

UPC:

810097260023

Alternate MPN:

PROHY8MSL

Warranty

1-Year Limited Warranty

DS18 warrants this product to be free from defects in material and workmanship under normal use and conditions for a period of one year from the date of purchase. This warranty covers any defects in materials and workmanship and warranty only applies to the original purchaser and is not transferable. DS18 will repair any part of your product that proves to be defective in materials or workmanship. In the event repair is not possible, DS18 will replace the product in question. If it is deemed necessary DS18 will either replace the entire product with a refurbished unit or it will be replaced with a model that is similar in price if that model is no longer available.

This warranty does not cover the cost for removal and reinstallation of any kind. This warranty is void and inapplicable DS18 deems that the product was abused or misused; including but not limited to Speaker product that has been improperly-powered, causing thermal coil failure and/or mechanical failure, damage caused by accident, mishandling, improper installation, negligence, normal wear and tear, excessive water or heat damage, and freight damage. DS18 is not responsible for any damages to a consumer's vehicle or person from a product failure. The warranty is void if DS18 deems the product was installed or used improperly. DS18 shall not be responsible for any incidental or consequential damages.

Refurbished units have a 90-day warranty.
