DS18® PRO-X698BM - PRO-X 6X9" Mid-Range Bullet Loudspeaker

2 reviews|Item # mpn5242749601
Universal Fit
Fitment notes:
  • Not Vehicle Specific
Authorized Dealer
$83.95
In Stock (657) - Ships in 2 to 3 days
Have a Question? Ask a Specialist
888-903-4343Live Chat

Vehicle Fitment

This part is universal

Specifications

SKU
PRO-X698BM
Nominal Diameter
6 x 9" / 152 x 228mm
Nominal Impedance
8 Ohm
RMS Power Handling
200W
MAX Power Handling
400W
Sensitivity (1w/1m)
96dB
Frequency Response
100Hz-12.5KHz
Recommended HI Pass Crossover
120HZ
Sold in Pair or Single
Single
Grill Included
Yes
Voice Coil Diameter
1.5" / 38.6mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Cone Material
Non-Pressed Paper
Bullet Material
Aluminum
Bullet Color/Finish
Glossy Red
Surround Material
Cloth
Basket Material
Steel
Basket Color/Finish
Glossy Red
Magnet Material
Ferrite
Magnet Weight
27 Oz
Displacement Volume
0.32L / 0.011ft3
Equivalent Volume
27.34L / 0.965ft3
Excursion (one way)
7.7mm
Free Air Resonance
120Hz
Mechanical Factor
5.342
Electrical Factor
0.768
Total Factor
0.687
Mechanical Mass
8.21g
Mechanical Compliance
0.234mm/N
BL Factor
6.84
Voice Coil Inductance
4.11mH
Cone Area
207.34cm2
DC Resistance
5.2 ohms
Overall Diameter
9.25 x 6.5" / 235 x 165mm
Overall Diameter With Grill
10.2 x 7.08" / 260 x 180mm
Overall Depth
3.5" / 88.85mm
Overall Depth With Grill
3.9" / 100mm
Front Mount Baffle Cutout
8.7 x 6" / 222 x 152mm
Mounting Depth
3.27" / 83mm
Motor Diameter
4.3" / 110mm

Features

  • 6x9" Mid-Range W/Bullet
  • MAX Power: 400 Watts
  • RMS Power: 200 Watts
  • Impedance: 8-Ohm
  • Ferrite Magnet
  • 96dB ~ w/Grill

Product Details

Universal PRO-X 6X9" Mid-Range Bullet Loudspeaker by DS18®. PRO-X 6X9" Mid-Range Bullet Loudspeaker 200W RMS 8-Ohm. 200W RMS 8-Ohm. PRO-X698BM . 6x9" Mid-Range Loudspeaker With Bullet . DS18’s PRO-X698BM brings unparalleled clarity to your car audio experience. These speakers set the gold standard for 6x9 car speaker upgrades. DS18’s PRO-X698BM has been engineered to deliver loud and powerful music without distortion. Its superior specs allow you to feel the intensity of a live concert from the comfort of your driver's seat. With an astounding 200W RMS power handling and a peak of 400W, you can push the limits of LOUD without sacrificing your quality. The attention to detail in construction speaks volumes; non-pressed paper cones paired with cloth surrounds are carefully housed in a steel basket, finished with a glossy red that makes a statement before the sound even hits. The included grill not only adds protection but also matches the overall design perfectly. The design features a 1.5" / 38.6mm 8 ohm voice coil made from Kapton, capable of withstanding high temperatures, guaranteeing longevity and consistent performance during the longest sessions. The PRO-X698BM features a high sensitivity of 96dB, allowing it to operate efficiently by converting power into clear, audible sound without a hint of distortion—even at extreme volume levels. With a frequency response spanning from 100Hz to 12.5KHz, every note is delivered with depth. By choosing the PRO-X698BM, you're investing in years of distortion-free audio that makes every drive unforgettable.

Brand:
Part Number:
PRO-X698BM
UPC:
810005181884
Alternate MPN:
PROX698BM

Reviews

(2)
Only authorized customers can leave a review on our website. We would love to know what you like or dislike about the product. Share your opinion on product quality, appearance, installation, and other characteristics.
/5
1-2 of 2 Reviews
5 of 5
Great Speakers
Great speakers, they sound amazing. Originally bought to replace the front speakers in my truck, both blown, the rear speakers still work and sound great. They are factory. But now I'm thinking about replacing them with DS18s as well because they sound so good. Don't fret when you get them delivered, they don't come with a plug. Simply cutting the plug off of the wiring in the truck, stripping the wire and wrapping around the piece of metal on the speaker where you'd think the plug would be does the trick. I would recommend these to anyone, and would be my first choice if I ever get another vehicle. And not to mention the price. I was amazed at how little they cost me, the factory speakers cost more than these! I'm rocking the bumper sticker they came with!
DS18® - Pro GM Series 6-1/2" 580W 8 Ohm Midrange Speaker with Bullet Diffuser
Posted by Braley (Shelbyville, MI) / July 25, 20222000 Chevy Silverado 2500
1 of 5
Sad
It can't handle power sad 500 watts cerwin vaga abt to pop it.
DS18® - Pro Series 8" 500W 4 Ohm Midrange Speaker with Bullet Diffuser
Posted by Anthony J (Eureka, CA) / July 18, 2021
