DS18® 8XL800N-8 - XL Mid-Range Loudspeaker with Neodymium Magnet

2 reviews|Item # mpn5242749493
Universal Fit
Fitment notes:
  • Not Vehicle Specific
Authorized Dealer
$239.95
In Stock (140) - Ships in 2 to 3 days
Have a Question? Ask a Specialist
888-903-4343Live Chat

Vehicle Fitment

This part is universal

Specifications

SKU
8XL800N-8
Nominal Diameter
8" / 203mm
Nominal Impedance
8 ohms
RMS Power Handling
400 watts
MAX Power Handling
800 watts
Sensitivity (1w/1m)
100.7dB
Frequency Response
100Hz-10KHz
Recommended High-Pass Crossover
160Hz
Sold in Pair or Single
Single
Grill Included
No
Interleaved Sandwich Voice coil (ISV)
No
Demodulating Rings
Yes
Improved Heat Dissipation
Yes
Cone Shape
Curvilinear
Speaker Terminals
Push 12ga
Voice Coil Diameter
2" / 50.8mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Cone Material
Non-pressed Paper
Dust Cap Material
Paper
Bullet Material
N/A
Bullet Color/Finish
N/A
Surround Material
Cloth
Spider Diameter
5" / 127mm
Leads Type
Direct to Cone
Basket Material
Aluminum
Basket Color/Finish
Satin Black
Magnet Material
Neodymium
Magnet Weight
7.5 Oz
Displacement Volume
0.03L / 0.00105ft3
Equivalent Volume Vas
17.09L / 0.603ft3
Excursion (one way) Xmax
2.3mm
Free Air Resonance Fs
87Hz
Mechanical Factor Qms
5.68
Electrical Factor Qes
0.27
Total Factor Qts
0.26
Mechanical Mass Mms
12.66g
Mechanical Compliance Cms
0.26mm/N
BL Factor BL
12
Voice Coil Inductance Le
0.06mH
Cone Area Sd
213.82cm2
DC Resistance Re
5.6 ohm
Mechanical Mass w/o air Mmd
11g
Overall Diameter
8.2" / 210mm
Overall Depth
3.85" / 98mm
Front Mount Baffle Cutout
7.2" / 183mm
Mounting Depth
3.38" / 86mm
Motor Diameter
4" / 102mm

Features

  • 8" Mid-Range
  • MAX Power: 800 Watts
  • RMS Power: 400 Watts
  • Impedance: 8-Ohm
  • Neodymium Magnet
  • 100.7dB

Product Details

Universal XL Mid-Range Loudspeaker with Neodymium Magnet (8XL800N-8) by DS18®. XL 8" Mid-Range Loudspeaker 8-Ohm with Neodymium Magnet 400 Watts RMS. DS18 8XL800N-8. 8" Mid-Range Loudspeaker With Neodymium Magnet 8-ohm . The 8XL800N-8 is designed to deliver mind-blowing clarity, making it the go-to choice for high-performance car audio systems. With an impressive power handling of 400W RMS and 800W MAX, you can reach extreme volumes while maintaining your audio’s integrity. Precision-Tuned Frequency Response . With a wide frequency response range of 100Hz – 10kHz, the 8XL800N-8 captures every detail of your favorite tracks. Delivering perfectly balanced sound across the midrange spectrum. Extreme Sensitivity for Maximum Output . With an insane 100.7dB sensitivity rating, this speaker produces incredibly high SPL (Sound Pressure Levels) with less power. It maximizes output without distortion, ensuring louder, clearer sound even in large vehicles and open spaces. Advanced Engineering for Superior Durability . The 2" Kapton voice coil provides exceptional heat resistance, allowing the speaker to handle extended play at high power levels without overheating. The non-pressed paper cone enhances audio accuracy and responsiveness, while the cloth surround ensures durability and smooth performance—even under extreme conditions. Lightweight Yet Powerful Neodymium Magnet . The 8XL800N-8 utilizes a lightweight yet incredibly powerful 7.5oz neodymium magnet. This high-strength magnetic system enhances speaker efficiency, ensuring tighter, punchier midrange frequencies with minimal distortion. Optimized for Versatile System Integration . Designed with a 8-ohm impedance, the 8XL800N-8 is highly versatile and integrates seamlessly into multi-speaker configurations. Its push-terminal connectors ensure secure and hassle-free installation, making it the perfect choice for custom audio builds. If you’re looking to crank up the volume without sacrificing clarity, DS18’s 8XL800N-8 is the perfect addition to your sound system.
