Gibson® 66573B - Black Elite™ 409 SS Cat-Back Exhaust System with Split Rear Exit

14 reviews|Item # mpn5201244702
Vehicle Specific
    Select Vehicle
    Notes:
    • Remember to check your local or state laws regarding vehicle noise restrictions and Emission Standards.
    Authorized Dealer
    $940.60
    In Stock (2) - Ships in 24 to 48 hrs
    See similar products
    Have a Question? Ask a Specialist
    888-903-4343Live Chat

    Vehicle Fitment

    Dodge
    Ram

    Specifications

    Exhaust System Type
    Cat-Back
    Exhaust Tubing Material
    409 SS
    Exit Location
    Split Rear (Straight Out The Back)
    Main Tubing Diameter
    2.5"
    Exhaust System Sound
    Aggressive / Loud
    Muffler Inlet Diameter
    3"
    Muffler Outlet Diameter
    2.5"
    Muffler Body Height
    4"
    Muffler Body Width
    9"
    Muffler Body Length
    13"
    Muffler Body Shape
    Oval
    Muffler Configuration
    Center Inlet - Dual Outlet
    Muffler Type
    Baffled & Chambered
    Tip Finish
    Black Ceramic Coated
    Tip Material
    304 SS
    Tip Inlet Diameter
    2.5"
    Tip Outlet Diameter
    5"
    Tip Length
    12"
    Tip Style
    Rolled
    Tip Cut Type
    Slash-Cut
    Tip Attachment Style
    Clamp-On
    Hardware Included
    All Hardware and Factory Style Hangers for Easy Bolt On Installation
    Additional Info
    Minimal Interior Drone

    Features

    • Stainless mandrel bent tubing
    • Black T304 Stainless Round Slash Cut Tip
    • Baffled & Chambered Design, No internal Packing, Minimal Interior Drone, Aggressive Sound
    • Includes all hardware and factory style hangers for easy bolt on installation
    • Lifetime Limited Warranty

    Product Details

    Black Elite™ 409 SS Cat-Back Exhaust System with Split Rear Exit by Gibson®. Exhaust System Type: Cat-Back. Exhaust Tubing Material: 409 SS. Main Tubing Diameter: 2.5". Exhaust System Sound: Aggressive / Loud. The Black Elite Series product line truly displays Gibson’s commitment to dominating performance and style. Each T-304 stainless tip is offered with a premium black finish applied with Gibson’s formulated process exclusive only to the Black Elite Series. For increased style and Performance, the series pushes the sound through proven stainless steel Superflow Muffler giving you a vigorous deep tone. It’s manufactured with high quality stainless steel tubing and backed by a limited lifetime warranty. With this perfect combination, Gibson Performance exceeds expectations with the ability to offer quality and style beating their competitors while being Made in the USA. Gibson Performance prides themselves on quality. The process is similar to the other diverse ranges of exhaust kits to maintain top quality with the added exclusive process to make it “Elite”.

    Installation

    Gibson® - Black Elite™ 409 SS Cat-Back Exhaust System Installation Instructions

    When you want to add some style to your truck or SUV, the Black Elite exhaust system offers unique 4" black ceramic exhaust tips that finish off the mandrel bent exhaust tubes exiting behind the rear tire for a look that sets your vehicle apart on the street or in the dirt. But aside from tough styling, the Black Elite exhaust system offers excellent performance from SuperFlow CFT Mufflers tuned specifically to each application for producing power and a deeper growl.


    Dominating the performance and style, the new Gibson Black Series is the ultimate choice. Designed for “THE” enthusiast, the stealth series pushes the power and sound through proven stainless steel SuperFlow Muffler, and high-quality Stainless Steel tubing to give you a vigorous deeper tone with the added performance. Each T-304 Stainless Tip is offered with a sleek black finish applied with unique formulated process exclusive only to customers whom choose the Black Series. Let the drive be your mission, leave the sound .

    Gibson® - Black Elite™ 409 SS Cat-Back Exhaust System Installation InstructionsGibson® - Exhaust TypesGibson® - CatalogGibson® - FAQGibson® - WarrantyMade In USAGibson Authorized DealerBenefitsAbout us
    Brand:
    Gibson
    Part Number:
    66573B
    UPC:
    677418034677

    Reviews

    (14)
    Only authorized customers can leave a review on our website. We would love to know what you like or dislike about the product. Share your opinion on product quality, appearance, installation, and other characteristics.
    /5
    1-10 of 14 Reviews
    5 of 5
    Nice Exhaust System
    I purchased this system in March 2022 for my 2008 4.7L engine. I was skeptical because of one review. I sought out help from others, but no negative or positive reviews. I decided to take a chance and ordered. I have been pleased ever since. The exhaust system always announces it self upon start up and roar beautifully when driving. Very impressed so far with this system. The Toyota techs were also impressed.
    Posted by Alan (New Haven, CT) / May 04, 20222008 Toyota Tundra
    2 of 5
    Will Not Fit Fwd Models!!!
    The description does not make it very clear that this is for the 4x4 models only. This will not fit fwd model, it will require modification to fit. Don't make the same mistake I did.
    Posted by Ian (Breaux Bridge, LA) / March 03, 20222016 Jeep Cherokee
    5 of 5
    Excellent Exhaust For My Ranger
    Quality and sturdy system, uses factory head pipe, which has the flex coupler up front. Was quite a simple install. Everything lines up perfectly, clears spare tire perfectly and the hanger posts all spot on. I skipped using the last section of pipe (for side exit) and just fastened the tip, which puts the exit at same level as bottom of spare tire, which provides perfect clearance for off roading/etc. Sounds great, just adds a minimal amount of noise compared to stock. I had been running an MBRP exhaust, which used a provided rigid head pipe, which never would seal good, even with tougher clamps, all the joints leaked, annoying. The Gibson has zero drone, even with skipping the last pipe section. Sounds great revving, quieter than the MBRP idling and no longer sounds like a diesel truck idling. Highly recommend.
    • youtube-video
    Posted by ryan (Granger, IN) / November 04, 20212021 Ford Ranger
    5 of 5
    You Will Not Regret It
    Super easy to install, the fit is perfect. The sound is great, meatier than stock without being obnoxious. Finally, the look of the black dual tip is very aggressive. Goes well with the three inch lift and larger than stock KO2 tires.
    Posted by Andrew (Seattle, WA) / September 30, 20202006 Toyota 4Runner
    3 of 5
    Sounds Good but Ticks and Pings
    Even after shutting the truck off it still makes ticking noises. Otherwise sounds ok.
    Posted by Customer / August 26, 20202019 Toyota 4Runner
    5 of 5
    Great Sound
    The system was easy to install and sounds AWESOME!!!
    Posted by Michael (San Mateo, FL) / July 20, 20202018 Toyota 4Runner
    5 of 5
    Don't Hesitate!
    Put this on a 2016 4runner with a paddle commander sounds amazing no drone. Took about an hour and a 1/2 for me and my buddy to put it on as long as you know how to turn a wrench. I love the sound this thing gives my vehicle it's not loud & obnoxious, but it's sounds like she's got something under the hood, ordering trd cia next.
    Posted by Rickey (Beech Creek, PA) / April 22, 20202016 Toyota 4Runner
    4 of 5
    Not What It Said It Would Be.
    So just put it on my truck and was surprised that it is quieter than my stock exhaust. It said in the description "aggressive sound" and it is anything but. Install was a breeze, looks great and seems to be well made, but way too quiet for my taste. I would not recommend this to a friend.
    Posted by John (Charlotte, NC) / September 06, 20192001 Ford F-250
    5 of 5
    Great Product. Better Customer Service
    The product was pretty easy to install. Although the instructions can be a little more detailed. I didn't realize the the head tube was just a butt fit with the existing pipe (I thought there would be a male/female fit). I called Gibson's customer service and he walked and talked me through the whole thing. Sounds and looks awesome.
    Posted by Craig (Redmond, WA) / November 22, 20182018 Chevy Silverado 1500
    3 of 5
    Sounds Great
    I bought this for my 2018 Tundra. Overall I'm happy with the look and the sound. Was a little quieter than expected but really nice deep tone. I was not impressed with the fit at all. Most of the joints had a half inch gap to fill. They give you male and female pipes to cinch together with clamps but there was no relief cuts or any type of gaskets to get a good seal. The clamps won't magically cinch down and seal a half inch gap.. I ended up making my own relief cuts with a grinder so I could at least get secure clamp. If you have a little time to put in its a great system. Not exactly a quick bolt on job as described.
    Posted by Brad (Tahoe Vista, CA) / October 11, 20182018 Toyota Tundra
