Holley® - Uscar Injector Harness with NTK Oxygen Sensor

Holley® 550-625N - Uscar Injector Harness with NTK Oxygen Sensor

0 reviews|Item # mpn5233451814

Vehicle SpecificCannot Confirm Fitment

We need more information

Confirm Fitment

Notes:

This is a Race Only product that is to be used solely for competition. It cannot be used on vehicles that are operated on public streets, roads or highways. Its use is limited to closed-course and open-course racing that is formally sanctioned by a recognized racing organization. Any other use, including recreational off-road use, could be in violation of local, state and federal laws. Shipping Restriction: CA, NY, ME.

Authorized Dealer

$4,149.95

In Stock (1) - Ships in 24 to 48 hrs

Have a Question? Ask a Specialist

888-903-4343Live Chat

Vehicle Fitment

Ford

Specifications

Emission Code	3
Fuel Filter Included	No
Fuel Injectors Included	No
Fuel Pump Included	No
Harness Application	Ford
Harness Type	Ignition
Ignition Type	Ford Coyote
Injector Connector	USCAR (EV6)
Throttle Position Sensor Included	No

Features

Now supports 2013-2015.5 Coyote engines
HP EFI kits available
Plug and Play main harness for 2013-2015.5 Coyote engines w/ stock cam shafts using stock coils (558- 110)
Plug and Play main harness for 2013-2015.5 Coyote engines w/ stock cam shafts using Holley EFI coils (558-122)
Compatible with HP or Dominator EFI
Pre-calibrated Ford sensor drop downs in the Holley EFI software
Ti-VCT Cam control down to 400 RPM
Commanded timing matched within 1 degree
User programmable tables enable the end user to fine tune aftermarket Ti-VCT compatible camshafts
4 Built in Diagnostic LEDS make diagnostics easy in the event of a cam or crank sensor failure
Integrated stock cam position tables – eliminate tuning guess work, optimal drive-ability and power right out of the box
Main harnesses come terminated with Ford TPS and IAC connectors, making it easy to convert from a DBW throttle body to a manual throttle body.
Installation of an external MAP sensor is required, recommend part number 538-13 for N/A applications
Main Harnesses includes a Power Tap Connector, as a convenient source for power and grounds when adding additional sensors or actuators
CANBus communication between Coyote Ti-VCT and Holley EFI ECU for high speed data transfer and diagnostics

Product Details

Uscar Injector Harness with NTK Oxygen Sensor by Holley®. Holley Performance Products has been the undisputed leader in fuel systems for over 100 years. Holley's products include carburetors, fuel pumps, fuel injection, intake manifolds, and much more. From start to finish, Holley has the parts to make your dream a reality.

Installation

Holley® - Uscar Injector Harness with NTK Oxygen Sensor Installation Instructions

Holley® - Uscar Injector Harness with NTK Oxygen Sensor Installation Instructions Holley® - Warranty Holley® - Catalogs Made In USA Holley Authorized Dealer FAQ Video About us

Brand:

Holley

Part Number:

550-625N

UPC:

090127030257

Alternate MPN:

550625N

Warranty

Holley warrants its products to be free from defects in materials or workmanship for a period of 90 days. The warranty period begins on the date the product is delivered.

Holley Performance Products Limited Warranty specifically does not apply to products, which have been (a) modified or altered in any way; (b) subjected to adverse conditions, such as misuse, neglect, accident, improper installation or adjustment, dirt or other contaminants, water, corrosion, or faulty repair; or (c) used in other than those applications recommended by Holley Performance Products. Holley Performance Products also does not warrant, and disclaims all liability for products used in racing activities and/or applications other than those specifically recommended in the current brand catalog.

Holley limits the warranty on Metallic Ceramic Coatings to be free from defects in material and workmanship for a period of 90 days from the date of purchase. This limited coating warranty does not apply to any products which have been subjected to adverse conditions, such as high heat encountered during engine break-in or if used during any racing activity.

Holley Performance Products warrants its new marine products to be free from defects in material and workmanship for a period of 90 days from date of purchase. For the safety and protection of persons and property, all United States Coast Guard and other marine product safety installation and use requirements and recommendations must be carefully studied and applied. The above recommendations include, but are not limited to the recommendation that the installation, adjustment, and repair of Holley carburetors or other marine products must be performed only by a trained mechanic having adequate marine fuel system experience, and in strict compliance with the applicable Holley installation, maintenance, and other instructions. Failure to follow such requirements and recommendations will void this Holley Marine Limited Warranty, and Holley disclaims any responsibility and/or liability for accidents resulting from such failure.

Holley® Performance Products warrants its Holley® Street Avenger™ Carburetor to be free from defects in material and workmanship for the life of the product on parts and one year on repair labor. After a period of one year, Holley® will charge standard rates for repair labor. For any Holley® Street Avenger™ Carburetor used in any type racing or off-road use will only be covered by a one (1) year limited warranty on parts and labor.

Holley® Performance Products warrants its Holley® Marine Avenger™ Carburetor to be free from defects in material and workmanship for the life of the product on parts and one year on repair labor. After a period of one year, Holley® will charge standard rates for repair labor. For any Holley® Marine Avenger™ Carburetor used in any type racing or off-road use will only be covered by a one (1) year limited warranty on parts and labor.
