LuK® DMF138 - Dual Mass Flywheel

7 reviews|Item # mpn4478643744
Vehicle Specific
    Select Vehicle
    Replaces Original (OE) Part #:2320025210
    Authorized Dealer
    $502.63
    In Stock (9) - Ships within 24 hrs
    See similar products
    Have a Question? Ask a Specialist
    888-903-4343Live Chat

    Vehicle Fitment

    Hyundai
    Kia

    Specifications

    Ring Gear Mounting O.D.
    10.098 inch
    Ring Gear Mounting O.D.
    256.5 mm
    Ring Gear To Friction Surface
    .965 inch
    Ring Gear To Friction Surface
    24.5 mm
    Ring Gear Thickness
    .547 inch
    Ring Gear Thickness
    13.9 mm
    Bolt Hole Pattern
    2
    Bolt hole PCD crankshaft
    2.677 inch
    Bolt hole PCD crankshaft
    68 mm
    Crank Hole Dia.
    .500 inch
    Crank Hole Dia.
    12.7 mm
    Bolt hole PCD clutch pres.plte
    10.079 inch
    Bolt hole PCD clutch pres.plte
    256 mm
    Flywheel Thickness [mm]
    2.260 inch
    Flywheel Thickness [mm]
    57.4 mm
    Ring Gear Chamfer matches OE
    Ring Gear Chamfer matches OE
    Flywheel friction surface outer diameter
    9.449 inch
    Flywheel friction surface outer diameter
    240 mm
    Flange Thickness
    .362 inch
    Flange Thickness
    9.2 mm
    Ring Gear Major Dia.
    11.075 inch
    Ring Gear Major Dia.
    281.3 mm
    Flywheel Friction Surface Inner diameter
    5.787 inch
    Flywheel Friction Surface Inner diameter
    147 mm
    Dowel Hole Pattern
    5
    I.D. for Pilot
    .591 inch
    I.D. for Pilot
    15 mm
    Dowel hole diameter
    .315 inch
    Dowel hole diameter
    8 mm
    Cup depth, secondary flywheel
    -.524 inch
    Cup depth, secondary flywheel
    -13.3 mm
    Overall Casting O.D.
    10.906 inch
    Overall Casting O.D.
    277 mm
    Number of teeth, starter ring gear
    110
    Centering diameter / dowel hole
    10.079 inch
    Centering diameter / dowel hole
    256 mm

    Features

    • Engineered and manufactured to OE specifications
    • All new components - including ring gear and dowel pins
    • Perfectly balanced
    • Precision-machined from premium grade cast iron
    • Superior quality friction surface
    • Excellent heat-absorbing capacity
    • Order from the comfort of your home or office
    • 8 mounting bores
    • With pilot bearing
    • No SVHC present

    Product Details

    Dual Mass Flywheel by LuK®. LuK dual mass flywheels absorb engine vibrations before they are transmitted to the driveline where they can create gear rattle. These units feature a built-in damper designed to isolate engine torque spikes and prevent transmission damage. By design, dual mass flywheels cannot be resurfaced.

    Installation

    LuK® - Installation Instructions

    The flywheel is an integral part of a clutch replacement. In today’s tightly packaged clutch systems, flywheels can easily be machined beyond their usable life – a critical flaw that would not be evident until after the clutch is installed. Improper machining can also cause interference, no release and slipping problems. Pairing your LuK RepSet with a new LuK flywheel is a smart, cost-effective alternative to resurfacing.

    LuK® - ManualLuK® - Installation InstructionsLuK Authorized DealerInstallationAdditional InformationAbout us
    Brand:
    LuK
    Part Number:
    DMF138
    UPC:
    670774369254
    OE Numbers:
    2320025210
